1462200100

Product image
Product thumb
Part No :

1462200100

Manufacturer
Woodhead - Molex
VIGOR # :

4072127

Description
RF ANT 1.561/1.575GHZ PCB 100MM
Catalog
RF Antennas
DataSheet
1462200100 PDF
Country of origin
-
Date code
-
ads
1462200100 Specifications
Type Description
Series:146220
Package:Bulk
Part Status:Active
RF Family/Standard:Navigation, WiFi
Frequency Group:Wide Band
Frequency (Center/Band):1.561GHz, 1.575GHz, 1.602GHz, 2.4GHz, 5GHz
Frequency Range:5.15GHz ~ 5.85GHz, 3GHz ~ 6GHz
Antenna Type:PCB Trace
Number of Bands:5
VSWR:-
Return Loss:-8dB
Gain:2.4dBi, 2.9dBi, 3.5dBi, 3.8dBi
Power - Max:2 W
Features:Cable - 100mm
Termination:U.FL (UMCC), IPEX MHF1
Ingress Protection:-
Mounting Type:Adhesive
Height (Max):0.032" (0.81mm)
Applications:BeiDou, GLONASS, WiMax, WLAN, Wi-Fi
  • Please confirm the specifications of the products when ordering.
  • MOQ means the minimum order quantity required to purchase each parts.
  • If you have special order instructions,please note it on the ordering pages.
  • The Pre-Shipment Inspection (PSI) will be applied.
  • You can email us to change the order details before shipment.
  • Orders cannot be canceled after shipping the packages.
  • TT in advance (bank transfer), Credit Card, PayPal can be chosen.
  • Cash transfer only. (Transfer with checks and bills are not accepted.)
  • Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
  • If you need the detailed invoice or tax ID,please email us.
  • FedEx, DHL, and UPS can be selected.
  • You can select whether to charge shipping fee by your shipping account or to charge by our side.
  • Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
  • The shopping cart will automatically calculate the shipping cost.
  • Delivery time: At the same day (Order deadline is 2pm, HK Time).
  • Delivery date: usually 2 to 7 working days.
  • It is unable to appoint a date of delivery.
  • Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)
In Stock: 1002
Shipped from
HK warehouse
Expected Shipping Date
Dec 28 - Jan 01 2025
Pricing(USD)
Quantity Unit Price Ext. Price
1 $3.21 $3.21
10 $2.86 $28.64
25 $2.58 $64.44
100 $2.35 $234.84
250 $2.12 $529.82
500 $1.90 $950.81
1000 $1.60 $1 603.79
2500 $1.52 $3 809.00
5000 $1.47 $7 331.60

Current price of 1462200100 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
