DPX205950DT-9108A1

Image is for reference,
please contact us to get the real picture

Part No :: DPX205950DT-9108A1

Manufacturer: TDK Corporation

Description: RF DIPLEXER 2.4GHZ/5.425GHZ 0805

Catalog: RF Multiplexers

DataSheet: DPX205950DT-9108A1 PDF

Availability: 10381 pieces

Unit Price: ~~$1.15000~~

Current price of DPX205950DT-9108A1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

DPX205950DT-9108A1 Specifications

Type	Description
Series:	DPX
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Diplexer
Frequency Bands (Low / High):	2.3GHz ~ 2.5GHz / 4.9GHz ~ 5.95GHz
Low Band Attenuation (min / max dB):	20.00dB / -
High Band Attenuation (min / max dB):	20.00dB / -
Return Loss (Low Band / High Band):	20.0dB / 11.0dB
Mounting Type:	Surface Mount
Package / Case:	0805 (2012 Metric), 6 PC Pad
