JSW2-63DR+

Part No :: JSW2-63DR+

Manufacturer

Description: REFLECTIVE SPDT, SMT SOLID STATE

Catalog: RF Switches

DataSheet: JSW2-63DR+ PDF

Availability: 0 pieces

Current price of JSW2-63DR+ is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

JSW2-63DR+ Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
RF Type:	CATV, SatCom
Topology:	Reflective
Circuit:	SPDT
Frequency Range:	5MHz ~ 6GHz
Isolation:	21dB
Insertion Loss:	0.57dB
Test Frequency:	6GHz
P1dB:	-
IIP3:	62dBm
Features:	-
Impedance:	50Ohm
Voltage - Supply:	2.3V ~ 4.8V
Operating Temperature:	-40°C ~ 85°C
Package / Case:	12-UFQFN Exposed Pad
Supplier Device Package:	12-QFN (2x2)
