AS5145A-HSST-500

Image is for reference,
please contact us to get the real picture

Part No :: AS5145A-HSST-500

Manufacturer: ams

Description: ROTARY ENCODER MAGNETIC 1024PPR

Catalog: Encoders

DataSheet: AS5145A-HSST-500 PDF

Availability: 0 pieces

Unit Price: ~~$0.00000~~

Current price of AS5145A-HSST-500 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AS5145A-HSST-500 Specifications

Type	Description
Series:	Automotive, AEC-Q100
Package:	Tape & Reel (TR)
Part Status:	Active
Encoder Type:	Magnetic
Output Type:	Quadrature (Incremental)
Pulses per Revolution:	1024
Voltage - Supply:	3V ~ 3.6V, 4.5V ~ 5.5V
Actuator Type:	External Magnet, Not Included
Detent:	No
Built in Switch:	No
Mounting Type:	Surface Mount
Orientation:	-
Termination Style:	SMD (SMT) Tab
Rotational Life (Cycles Min):	-
