AH3369Q-P-B

Part No :: AH3369Q-P-B

Manufacturer: Zetex Semiconductors (Diodes Inc.)

Description: MAGNETIC SWITCH UNIPOLAR 3SIP

Catalog: Magnetic Sensors - Switches (Solid State)

DataSheet: AH3369Q-P-B PDF

Availability: 150123000 pieces

Unit Price: ~~$1.01000~~

Current price of AH3369Q-P-B is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AH3369Q-P-B Specifications

Type	Description
Series:	Automotive, AEC-Q100
Package:	Bulk
Part Status:	Active
Function:	Unipolar Switch
Technology:	Hall Effect
Polarization:	South Pole
Sensing Range:	17.5mT Trip, 1mT Release
Test Condition:	25°C
Voltage - Supply:	3V ~ 28V
Current - Supply (Max):	4mA
Current - Output (Max):	60mA
Output Type:	Open Drain
Features:	-
Operating Temperature:	-40°C ~ 150°C (TA)
Mounting Type:	Through Hole
Supplier Device Package:	3-SIP
Package / Case:	3-SIP
