AH3765Q-W-7

Part No :: AH3765Q-W-7

Manufacturer: Zetex Semiconductors (Diodes Inc.)

Description: MAGNETIC SWITCH LATCH SC59

Catalog: Magnetic Sensors - Switches (Solid State)

DataSheet: AH3765Q-W-7 PDF

Availability: 21000 pieces

Unit Price: ~~$0.39195~~

Current price of AH3765Q-W-7 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AH3765Q-W-7 Specifications

Type	Description
Series:	Automotive, AEC-Q100
Package:	Tape & Reel (TR)
Part Status:	Active
Function:	Latch
Technology:	Hall Effect
Polarization:	South Pole
Sensing Range:	9mT Trip, -9mT Release
Test Condition:	-40°C ~ 150°C
Voltage - Supply:	3V ~ 28V
Current - Supply (Max):	4mA
Current - Output (Max):	60mA
Output Type:	Open Drain
Features:	Temperature Compensated
Operating Temperature:	-40°C ~ 150°C (TA)
Mounting Type:	Surface Mount
Supplier Device Package:	SC-59
Package / Case:	TO-236-3, SC-59, SOT-23-3

Please confirm the specifications of the products when ordering.
