AH3769Q-P-B

Part No :: AH3769Q-P-B

Manufacturer: Zetex Semiconductors (Diodes Inc.)

Description: MAGNETIC SWITCH LATCH 3SIP

Catalog: Magnetic Sensors - Switches (Solid State)

DataSheet: AH3769Q-P-B PDF

Availability: 629 pieces

Unit Price: ~~$1.05000~~

Current price of AH3769Q-P-B is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AH3769Q-P-B Specifications

Type	Description
Series:	Automotive, AEC-Q100
Package:	BulkBulk
Part Status:	Active
Function:	Latch
Technology:	Hall Effect
Polarization:	South Pole
Sensing Range:	25mT Trip, -25mT Release
Test Condition:	-40°C ~ 150°C
Voltage - Supply:	3V ~ 28V
Current - Supply (Max):	4mA
Current - Output (Max):	60mA
Output Type:	Open Drain
Features:	Temperature Compensated
Operating Temperature:	-40°C ~ 150°C (TA)
Mounting Type:	Through Hole
Supplier Device Package:	3-SIP
Package / Case:	3-SIP Module
