AD106-00E

Part No :: AD106-00E

Manufacturer: NVE Corporation

Description: MAGNETIC SWITCH OMNIPOLAR 8MSOP

Catalog: Magnetic Sensors - Switches (Solid State)

DataSheet: AD106-00E PDF

Availability: 0 pieces

Unit Price: ~~$1.48190~~

Current price of AD106-00E is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AD106-00E Specifications

Type	Description
Series:	AD
Package:	Tube
Part Status:	Active
Function:	Omnipolar Switch
Technology:	Hall Effect
Polarization:	North Pole, South Pole
Sensing Range:	±10mT Trip, ±6.5mT Release
Test Condition:	-40°C ~ 125°C
Voltage - Supply:	4.5V ~ 30V
Current - Supply (Max):	4.5mA
Current - Output (Max):	20mA
Output Type:	Open Collector
Features:	-
Operating Temperature:	-40°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Supplier Device Package:	8-MSOP
Package / Case:	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
