AM1P-0524SH30Z vs AM1PS-0524SH30JZ

This detailed comparison of AM1P-0524SH30Z and AM1PS-0524SH30JZ in the DC DC Converters provides valuable insights into their specifications and features. Key aspects such as Manufacturer, Package, Mounting Type, and core parameters are thoroughly analyzed. This side-by-side comparison simplifies component selection. To learn more, explore their datasheets or request a quote directly.

AM1P-0524SH30Z

DComponents

Request For Quote

AM1PS-0524SH30JZ

DComponents

Request For Quote

Specifications Hide identical items

Manufacturer	DComponents	DComponents
Package / Case	8-DIP Module, 4 Leads	8-DIP Module, 4 Leads
Description	DC DC CONVERTER 24V 1.2W	DC DC CONVERTER 24V 1W
In Stock	1 279	1 180
Mounting Type	Through Hole	Through Hole
Part Status	Active	Active
Series	AM1P-Z (1W)	AM1PS-JZ (1W)
Package	Tube	Tube
Type	Isolated Module	Isolated Module
Number of Outputs	1	1
Voltage - Input (Min)	4.5V	4.5V
Voltage - Input (Max)	5.5V	5.5V
Voltage - Output 1	24V	24V
Voltage - Output 2	-	-
Voltage - Output 3	-	-
Voltage - Output 4	-	-
Current - Output (Max)	50mA	42mA
Power (Watts)	1.2 W	1 W
Voltage - Isolation	3 kV	3 kV
Applications	ITE (Commercial)	ITE (Commercial)
Features	-	-
Operating Temperature	-40°C ~ 85°C	-40°C ~ 85°C (With Derating)
Efficiency	82%	85%
Size / Dimension	0.50" L x 0.40" W x 0.27" H (12.7mm x 10.2mm x 6.9mm)	0.50" L x 0.40" W x 0.32" H (12.7mm x 10.2mm x 8.2mm)
Supplier Device Package	-	-
Control Features	-	-
Approval Agency	CE	cULus, cURus
Standard Number	-	-
