K7805-3AR3 vs PT6322R

This detailed comparison of K7805-3AR3 and PT6322R in the DC DC Converters provides valuable insights into their specifications and features. Key aspects such as Manufacturer, Package, Mounting Type, and core parameters are thoroughly analyzed. This side-by-side comparison simplifies component selection. To learn more, explore their datasheets or request a quote directly.

K7805-3AR3

Mornsun

Request For Quote

PT6322R

Texas Instruments

Request For Quote

Specifications Hide identical items

Manufacturer	Mornsun	Texas Instruments
Package / Case	12-SIP Module	12-SIP Module
Description	DC DC CONVERTER 5V 15W	DC DC CONVERTER 5V
In Stock	1 096	1 629
Mounting Type	Through Hole	Through Hole
Part Status	Active	Obsolete
Series	K7805-3AR3	PT6320
Package	Tube	Tray
Type	Non-Isolated PoL Module	Non-Isolated PoL Module
Number of Outputs	1	1
Voltage - Input (Min)	8V	7V
Voltage - Input (Max)	36V	38V
Voltage - Output 1	5V	5V
Voltage - Output 2	-	-
Voltage - Output 3	-	-
Voltage - Output 4	-	-
Current - Output (Max)	3A	3A
Power (Watts)	15 W	-
Voltage - Isolation	-	-
Applications	ITE (Commercial)	ITE (Commercial)
Features	-	-
Operating Temperature	-40°C ~ 85°C	-40°C ~ 85°C
Efficiency	93%	89%
Size / Dimension	1.27" L x 0.36" W x 0.58" H (32.2mm x 9.1mm x 14.9mm)	-
Supplier Device Package	-	-
Control Features	-	-
Approval Agency	CE	-
Standard Number	-	-
