NME1209SC vs 1S4E_1209S1U

This detailed comparison of NME1209SC and 1S4E_1209S1U in the DC DC Converters provides valuable insights into their specifications and features. Key aspects such as Manufacturer, Package, Mounting Type, and core parameters are thoroughly analyzed. This side-by-side comparison simplifies component selection. To learn more, explore their datasheets or request a quote directly.

NME1209SC

Murata Power Solutions

Request For Quote

1S4E_1209S1U

TE Connectivity AMP Connectors

Request For Quote

Specifications Hide identical items

Manufacturer	Murata Power Solutions	TE Connectivity AMP Connectors
Package / Case	4-SIP Module	4-SIP Module
Description	DC DC CONVERTER 9V 1W	DC-DC
In Stock	1 346	574
Mounting Type	Through Hole	Through Hole
Part Status	Active	Active
Series	NME (1W)	1S4E_S1U (1W)
Package	Tube	Tube
Type	Isolated Module	Isolated Module
Number of Outputs	1	1
Voltage - Input (Min)	10.8V	10.8V
Voltage - Input (Max)	13.2V	13.2V
Voltage - Output 1	9V	9V
Voltage - Output 2	-	-
Voltage - Output 3	-	-
Voltage - Output 4	-	-
Current - Output (Max)	111mA	111.1mA
Power (Watts)	1 W	1 W
Voltage - Isolation	1 kV	1 kV
Applications	ITE (Commercial)	ITE (Commercial)
Features	-	-
Operating Temperature	-40°C ~ 85°C	-40°C ~ 85°C
Efficiency	74%	78%
Size / Dimension	0.45" L x 0.24" W x 0.39" H (11.4mm x 6.1mm x 9.9mm)	0.46" L x 0.24" W x 0.40" H (11.7mm x 6.0mm x 10.2mm)
Supplier Device Package	-	-
Control Features	-	-
Approval Agency	-	CE
Standard Number	-	60950-1
