R-7312D vs R-6212D

This detailed comparison of R-7312D and R-6212D in the DC DC Converters provides valuable insights into their specifications and features. Key aspects such as Manufacturer, Package, Mounting Type, and core parameters are thoroughly analyzed. This side-by-side comparison simplifies component selection. To learn more, explore their datasheets or request a quote directly.

R-7312D

RECOM Power

Request For Quote

R-6212D

RECOM Power

Request For Quote

Specifications Hide identical items

Manufacturer	RECOM Power	RECOM Power
Package / Case	12-SIP Module	12-SIP Module
Description	DC DC CONVERTER 12V 36W	DC DC CONVERTER 12V 24W
In Stock	128	1 465
Mounting Type	Through Hole, Right Angle	Through Hole, Right Angle
Part Status	Active	Active
Series	INNOLINE R-7xxx	INNOLINE R-6xxx
Package	Tube	Tube
Type	Non-Isolated PoL Module	Non-Isolated PoL Module
Number of Outputs	1	1
Voltage - Input (Min)	15V	14V
Voltage - Input (Max)	28V	32V
Voltage - Output 1	12V	12V
Voltage - Output 2	-	-
Voltage - Output 3	-	-
Voltage - Output 4	-	-
Current - Output (Max)	3A	2A
Power (Watts)	36 W	24 W
Voltage - Isolation	-	-
Applications	ITE (Commercial)	ITE (Commercial)
Features	Remote On/Off, SCP	Remote On/Off, SCP
Operating Temperature	-40°C ~ 85°C	-40°C ~ 85°C
Efficiency	97%	96%
Size / Dimension	1.27" L x 0.59" W x 0.36" H (32.2mm x 15.0mm x 9.1mm)	1.27" L x 0.59" W x 0.36" H (32.2mm x 15.0mm x 9.1mm)
Supplier Device Package	-	-
Control Features	Enable, Active High	Enable, Active High
Approval Agency	-	-
Standard Number	-	-
