SMCJ22A-E3/9AT

Part No :: SMCJ22A-E3/9AT

Manufacturer: Vishay General Semiconductor – Diodes Division

Description: TVS DIODE 22V 35.5V DO214AB

Catalog: TVS - Diodes

DataSheet: SMCJ22A-E3/9AT PDF

Availability: 0 pieces

Current price of SMCJ22A-E3/9AT is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SMCJ22A-E3/9AT Specifications

Type	Description
Series:	TransZorb®
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Zener
Unidirectional Channels:	1
Bidirectional Channels:	-
Voltage - Reverse Standoff (Typ):	22V
Voltage - Breakdown (Min):	24.4V
Voltage - Clamping (Max) @ Ipp:	35.5V
Current - Peak Pulse (10/1000µs):	42.3A
Power - Peak Pulse:	1500W (1.5kW)
Power Line Protection:	No
Applications:	General Purpose
Capacitance @ Frequency:	-
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	DO-214AB, SMC
Supplier Device Package:	DO-214AB (SMCJ)
