SMAJ8.5AHR3G

Part No :: SMAJ8.5AHR3G

Manufacturer: TSC (Taiwan Semiconductor)

Description: TVS DIODE 8.5V 14.4V DO214AC

Catalog: TVS - Diodes

DataSheet: SMAJ8.5AHR3G PDF

Availability: 3490 pieces

Current price of SMAJ8.5AHR3G is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SMAJ8.5AHR3G Specifications

Type	Description
Series:	Automotive, AEC-Q101, SMAJ
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Zener
Unidirectional Channels:	1
Bidirectional Channels:	-
Voltage - Reverse Standoff (Typ):	8.5V
Voltage - Breakdown (Min):	9.44V
Voltage - Clamping (Max) @ Ipp:	14.4V
Current - Peak Pulse (10/1000µs):	27.8A
Power - Peak Pulse:	400W
Power Line Protection:	No
Applications:	Automotive
Capacitance @ Frequency:	-
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	DO-214AC, SMA
Supplier Device Package:	DO-214AC (SMA)
