PTVS22VP1UP,115

Part No :: PTVS22VP1UP,115

Manufacturer: Nexperia

Description: TVS DIODE 22V 35.5V CFP5

Catalog: TVS - Diodes

DataSheet: PTVS22VP1UP,115 PDF

Availability: 6437 pieces

Current price of PTVS22VP1UP,115 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

PTVS22VP1UP,115 Specifications

Type	Description
Series:	Automotive, AEC-Q101
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Zener
Unidirectional Channels:	1
Bidirectional Channels:	-
Voltage - Reverse Standoff (Typ):	22V
Voltage - Breakdown (Min):	24.4V
Voltage - Clamping (Max) @ Ipp:	35.5V
Current - Peak Pulse (10/1000µs):	16.9A
Power - Peak Pulse:	600W
Power Line Protection:	No
Applications:	Automotive
Capacitance @ Frequency:	-
Operating Temperature:	-55°C ~ 150°C (TA)
Mounting Type:	Surface Mount
Package / Case:	SOD-128
Supplier Device Package:	CFP5
