SMCJ36CAQ-13-F

Part No :: SMCJ36CAQ-13-F

Manufacturer: Zetex Semiconductors (Diodes Inc.)

Description: TRANSIENT VOLTAGE SUPPRESSOR,SMC

Catalog: TVS - Diodes

DataSheet: SMCJ36CAQ-13-F PDF

Availability: 321 pieces

Current price of SMCJ36CAQ-13-F is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SMCJ36CAQ-13-F Specifications

Type	Description
Series:	Automotive, AEC-Q101
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Zener
Unidirectional Channels:	-
Bidirectional Channels:	1
Voltage - Reverse Standoff (Typ):	36V
Voltage - Breakdown (Min):	40V
Voltage - Clamping (Max) @ Ipp:	58.1V
Current - Peak Pulse (10/1000µs):	25.8A
Power - Peak Pulse:	1500W (1.5kW)
Power Line Protection:	No
Applications:	Automotive
Capacitance @ Frequency:	-
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	DO-214AB, SMC
Supplier Device Package:	SMC
