AE324SD19PN-LC

Part No :: AE324SD19PN-LC

Manufacturer: PEI-Genesis

Description: CONN RCPT HSG MALE 19POS PNL MT

Catalog: Circular Connectors - Housings

DataSheet: AE324SD19PN-LC PDF

Availability: 32 pieces

Current price of AE324SD19PN-LC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AE324SD19PN-LC Specifications

Type	Description
Series:	MIL-DTL-38999 Series III
Package:	Box
Part Status:	Active
Connector Type:	Receptacle Housing
Type:	For Male Pins
Number of Positions:	19
Shell Size - Insert:	D-19
Shell Size, MIL:	-
Contact Type:	Crimp
Contact Size:	20
Mounting Type:	Panel Mount
Mounting Feature:	Bulkhead - Rear Side Nut
Fastening Type:	Threaded
Orientation:	N (Normal)
Shell Material:	Stainless Steel
Shell Finish:	Nickel
Housing Color:	-
Ingress Protection:	-
Material Flammability Rating:	-
Features:	-
Shielding:	Shielded
