AE156T19B28PA

Part No :: AE156T19B28PA

Manufacturer: PEI-Genesis

Description: CONN RCPT MALE 28POS GOLD CRIMP

Catalog: Circular Connectors

DataSheet: AE156T19B28PA PDF

Availability: 10 pieces

Current price of AE156T19B28PA is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AE156T19B28PA Specifications

Type	Description
Series:	MIL-DTL-38999 Series I
Package:	Box
Part Status:	Active
Connector Type:	Receptacle, Male Pins
Number of Positions:	28
Shell Size - Insert:	19-28
Shell Size, MIL:	-
Mounting Type:	Panel Mount
Mounting Feature:	Flange
Termination:	Crimp
Fastening Type:	Bayonet Lock
Orientation:	A
Shell Material:	Aluminum
Shell Finish:	Olive Drab Cadmium
Contact Finish - Mating:	Gold
Color:	Olive Drab
Ingress Protection:	-
Material Flammability Rating:	-
Features:	-
Shielding:	Shielded
Current Rating (Amps):	7.5A, 13A
Voltage Rating:	-
Cable Opening:	-
Operating Temperature:	-65°C ~ 175°C
