5228686-1

Part No :: 5228686-1

Manufacturer: TE Connectivity AMP Connectors

VIGOR # :: 3317720

Description: CONN TWINAX JACK R/A PCB

Catalog: Coaxial Connectors (RF)

DataSheet: 5228686-1 PDF

Country of origin: -

Date code: -

5228686-1 Specifications

Type	Description
Series:	Coaxicon
Package:	Bulk
Part Status:	Active
Connector Style:	BNC, Twinaxial
Connector Type:	Jack, Female Socket and Male Pin
Contact Termination:	Solder
Shield Termination:	Solder
Impedance:	Non-Constant
Mounting Type:	Panel Mount, Through Hole, Right Angle
Mounting Feature:	Bulkhead - Front Side Nut
Cable Group:	-
Fastening Type:	Bayonet Lock
Frequency - Max:	-
Number of Ports:	1
Features:	Board Guide, Isolated
Housing Color:	Natural, Silver
Ingress Protection:	-
