Type | Description |
---|---|
Series: | SFV-R |
Package: | Tape & Reel (TR)Cut Tape (CT) |
Part Status: | Active |
Flat Flex Type: | FPC |
Mounting Type: | Surface Mount, Right Angle |
Connector/Contact Type: | Contacts, Top |
Number of Positions: | 18 |
Pitch: | 0.020" (0.50mm) |
Termination: | Solder |
FFC, FCB Thickness: | 0.33mm |
Height Above Board: | 0.071" (1.80mm) |
Locking Feature: | Slide Lock |
Cable End Type: | Notched |
Contact Material: | Phosphor Bronze |
Contact Finish: | Gold |
Housing Material: | Liquid Crystal Polymer (LCP), Glass Filled, Halogen Free |
Actuator Material: | Polyphenylene Sulfide (PPS), Glass Filled, Halogen Free |
Features: | Solder Retention, Zero Insertion Force (ZIF) |
Voltage Rating: | 50V |
Operating Temperature: | -55°C ~ 105°C |
Material Flammability Rating: | UL94 V-0 |
