ZF1-12-01-TM-WT-TR

Part No :: ZF1-12-01-TM-WT-TR

Manufacturer: Samtec, Inc.

Description: 1.00 MM ZERO INSERTION FORCE FLA

Catalog: FFC, FPC (Flat Flexible) Connectors

DataSheet: ZF1-12-01-TM-WT-TR PDF

Availability: 0 pieces

Current price of ZF1-12-01-TM-WT-TR is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

ZF1-12-01-TM-WT-TR Specifications

Type	Description
Series:	ZF1
Package:	Tape & Reel (TR)
Part Status:	Active
Flat Flex Type:	FFC
Mounting Type:	Surface Mount, Right Angle
Connector/Contact Type:	Contacts, Bottom
Number of Positions:	12
Pitch:	0.039" (1.00mm)
Termination:	Solder
FFC, FCB Thickness:	0.30mm
Height Above Board:	0.118" (3.00mm)
Locking Feature:	Slide Lock
Cable End Type:	Straight
Contact Material:	Phosphor Bronze
Contact Finish:	Tin
Housing Material:	Liquid Crystal Polymer (LCP)
Actuator Material:	Polyphenylene Sulfide (PPS)
Features:	Solder Retention, Zero Insertion Force (ZIF)
Voltage Rating:	-
Operating Temperature:	-55°C ~ 105°C
Material Flammability Rating:	UL94 V-2
