H8505-05

Part No :: H8505-05

Manufacturer: Harwin

VIGOR # :: 3195309

Description: CONN PIN RCPT .023-.033 SOLDER

Catalog: Terminals - PC Pin Receptacles, Socket Connectors

DataSheet: H8505-05 PDF

Country of origin: -

Date code: -

H8505-05 Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Tail Type:	No Tail
Termination:	Solder
Length - Overall:	0.232" (5.89mm)
Accepts Pin Diameter:	0.024" ~ 0.033" (0.60mm ~ 0.85mm)
Accepts Square Pin Size:	-
Pin Hole Diameter:	-
Mounting Hole Diameter:	0.075" ~ 0.079" (1.91mm ~ 2.01mm)
Flange Diameter:	0.105" (2.67mm)
Tail Diameter:	-
Socket Depth:	0.183" (4.65mm)
Contact Material:	Beryllium Copper
Contact Finish:	Gold
Contact Finish Thickness:	5.90µin (0.150µm)
