HMC509LP5ETR

Part No :: HMC509LP5ETR

Manufacturer: Linear Technology (Analog Devices, Inc.)

Description: VCO 4.15GHZ/8.3GHZ 2-13V 5X5MM

Catalog: VCOs (Voltage Controlled Oscillators)

DataSheet: HMC509LP5ETR PDF

Availability: 560 pieces

Current price of HMC509LP5ETR is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

HMC509LP5ETR Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Frequency Range:	3.9 ~ 4.4GHz, 7.8 ~ 8.8GHz
Frequency - Center:	4.15GHz, 8.3GHz
Voltage - Supply:	5V
Tuning Voltage (VDC):	2 V ~ 13.0 V
2nd Harmonic, Typ (dBc):	10
Icc Max:	270mA
Pushing (MHz/V):	10
Power (dBm):	7.5±2.5, 12.5±2.5
Phase Noise Typ (dBc/Hz):	-115
Operating Temperature:	-40°C ~ 85°C
Package / Case:	32-VFQFN Exposed Pad, CSP
Size / Dimension:	0.197" L x 0.197" W (5.00mm x 5.00mm)
Height:	0.039" (1.00mm)

Please confirm the specifications of the products when ordering.
