BAW56-G

Product image
Product thumb
Part No :

BAW56-G

Manufacturer
Comchip Technology
VIGOR # :

2945467

Description
DIODE ARRAY GP 70V 215MA SOT23
Catalog
Diodes - Rectifiers - Arrays
DataSheet
BAW56-G PDF
Country of origin
-
Date code
-
ads
BAW56-G Specifications
Type Description
Series:-
Package:Tape & Reel (TR)Cut Tape (CT)
Part Status:Active
Diode Configuration:1 Pair Common Anode
Diode Type:Standard
Voltage - DC Reverse (Vr) (Max):70 V
Current - Average Rectified (Io) (per Diode):215mA (DC)
Voltage - Forward (Vf) (Max) @ If:1.25 V @ 150 mA
Speed:Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr):6 ns
Current - Reverse Leakage @ Vr:2.5 µA @ 70 V
Operating Temperature - Junction:-55°C ~ 150°C
Mounting Type:Surface Mount
Package / Case:TO-236-3, SC-59, SOT-23-3
Supplier Device Package:SOT-23-3
