SDM1100LP-7

SDM1100LP-7 Specifications

Type	Description
Series:	Automotive, AEC-Q101
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Diode Type:	Schottky
Voltage - DC Reverse (Vr) (Max):	100 V
Current - Average Rectified (Io):	1A
Voltage - Forward (Vf) (Max) @ If:	770 mV @ 1 A
Speed:	Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr):	-
Current - Reverse Leakage @ Vr:	350 µA @ 100 V
Capacitance @ Vr, F:	40pF @ 5V, 1MHz
Mounting Type:	Surface Mount
Package / Case:	2-UFDFN
Supplier Device Package:	U-DFN2020-2
Operating Temperature - Junction:	-55°C ~ 175°C
