LL103A-GS08

Part No :: LL103A-GS08

Manufacturer: Vishay General Semiconductor – Diodes Division

Description: DIODE SCHOTTKY 40V 200MA SOD80

Catalog: Diodes - Rectifiers - Single

DataSheet: LL103A-GS08 PDF

Availability: 17284 pieces

Current price of LL103A-GS08 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

LL103A-GS08 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Diode Type:	Schottky
Voltage - DC Reverse (Vr) (Max):	40 V
Current - Average Rectified (Io):	200mA
Voltage - Forward (Vf) (Max) @ If:	600 mV @ 200 mA
Speed:	Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr):	10 ns
Current - Reverse Leakage @ Vr:	5 µA @ 30 V
Capacitance @ Vr, F:	50pF @ 0V, 1MHz
Mounting Type:	Surface Mount
Package / Case:	DO-213AC, MINI-MELF, SOD-80
Supplier Device Package:	SOD-80 MiniMELF
Operating Temperature - Junction:	125°C (Max)
