NSR05301MX4T5G

Part No :: NSR05301MX4T5G

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 2924898

Description: 01005_TRENCH_SCHOTTKY_30V

Catalog: Diodes - Rectifiers - Single

DataSheet: NSR05301MX4T5G PDF

Country of origin: -

Date code: -

NSR05301MX4T5G Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Diode Type:	Schottky
Voltage - DC Reverse (Vr) (Max):	30 V
Current - Average Rectified (Io):	500mA (DC)
Voltage - Forward (Vf) (Max) @ If:	800 mV @ 500 mA
Speed:	Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr):	11 ns
Current - Reverse Leakage @ Vr:	100 µA @ 30 V
Capacitance @ Vr, F:	19pF @ 5V, 1MHz
Mounting Type:	Surface Mount
Package / Case:	01005 (0402 Metric)
Supplier Device Package:	2-X4DFN (0.45x0.24)
Operating Temperature - Junction:	-55°C ~ 125°C
