SE20PBHM3/84A

Part No :: SE20PBHM3/84A

Manufacturer: Vishay General Semiconductor – Diodes Division

Description: DIODE GEN PURP 100V 1.6A DO220AA

Catalog: Diodes - Rectifiers - Single

DataSheet: SE20PBHM3/84A PDF

Availability: 0 pieces

Unit Price: ~~$0.10605~~

Current price of SE20PBHM3/84A is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SE20PBHM3/84A Specifications

Type	Description
Series:	Automotive, AEC-Q101
Package:	Tape & Reel (TR)
Part Status:	Active
Diode Type:	Standard
Voltage - DC Reverse (Vr) (Max):	100 V
Current - Average Rectified (Io):	1.6A (DC)
Voltage - Forward (Vf) (Max) @ If:	1.05 V @ 2 A
Speed:	Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr):	1.2 µs
Current - Reverse Leakage @ Vr:	5 µA @ 100 V
Capacitance @ Vr, F:	13pF @ 4V, 1MHz
Mounting Type:	Surface Mount
Package / Case:	DO-220AA
Supplier Device Package:	DO-220AA (SMP)
Operating Temperature - Junction:	-55°C ~ 175°C

Please confirm the specifications of the products when ordering.
