S12JCHR7G

Part No :: S12JCHR7G

Manufacturer: TSC (Taiwan Semiconductor)

Description: DIODE GEN PURP 600V 12A DO214AB

Catalog: Diodes - Rectifiers - Single

DataSheet: S12JCHR7G PDF

Availability: 0 pieces

Unit Price: ~~$0.26946~~

Current price of S12JCHR7G is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

S12JCHR7G Specifications

Type	Description
Series:	Automotive, AEC-Q101
Package:	Tape & Reel (TR)
Part Status:	Active
Diode Type:	Standard
Voltage - DC Reverse (Vr) (Max):	600 V
Current - Average Rectified (Io):	12A
Voltage - Forward (Vf) (Max) @ If:	1.1 V @ 12 A
Speed:	Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr):	-
Current - Reverse Leakage @ Vr:	1 µA @ 600 V
Capacitance @ Vr, F:	78pF @ 4V, 1MHz
Mounting Type:	Surface Mount
Package / Case:	DO-214AB, SMC
Supplier Device Package:	DO-214AB (SMC)
Operating Temperature - Junction:	-55°C ~ 150°C
