BDW42G

Part No :: BDW42G

Manufacturer: Sanyo Semiconductor/ON Semiconductor

Description: TRANS NPN DARL 100V 15A TO220AB

Catalog: Transistors - Bipolar (BJT) - Single

DataSheet: BDW42G PDF

Availability: 0 pieces

Current price of BDW42G is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

BDW42G Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Transistor Type:	NPN - Darlington
Current - Collector (Ic) (Max):	15 A
Voltage - Collector Emitter Breakdown (Max):	100 V
Vce Saturation (Max) @ Ib, Ic:	3V @ 50mA, 10A
Current - Collector Cutoff (Max):	2mA
DC Current Gain (hFE) (Min) @ Ic, Vce:	1000 @ 5A, 4V
Power - Max:	85 W
Frequency - Transition:	4MHz
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Package / Case:	TO-220-3
Supplier Device Package:	TO-220AB
