DMG8822UTS-13

Part No :: DMG8822UTS-13

Manufacturer: Zetex Semiconductors (Diodes Inc.)

VIGOR # :: 2979286

Description: MOSFET 2N-CH 20V 4.9A 8TSSOP

Catalog: Transistors - FETs, MOSFETs - Arrays

DataSheet: DMG8822UTS-13 PDF

Current price of DMG8822UTS-13 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

DMG8822UTS-13 Specifications

Type	Description
Series:	Automotive, AEC-Q101
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	2 N-Channel (Dual) Common Drain
FET Feature:	Standard
Drain to Source Voltage (Vdss):	20V
Current - Continuous Drain (Id) @ 25°C:	4.9A (Ta)
Rds On (Max) @ Id, Vgs:	25mOhm @ 8.2A, 4.5V
Vgs(th) (Max) @ Id:	900mV @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	9.6nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds:	841pF @ 10V
Power - Max:	870mW
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	8-TSSOP (0.173", 4.40mm Width)
Supplier Device Package:	8-TSSOP
