FDG6316P

Part No :: FDG6316P

Manufacturer: Sanyo Semiconductor/ON Semiconductor

Description: MOSFET 2P-CH 12V 0.7A SC70-6

Catalog: Transistors - FETs, MOSFETs - Arrays

DataSheet: FDG6316P PDF

Availability: 14077 pieces

Unit Price: ~~$0.46000~~

Current price of FDG6316P is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

FDG6316P Specifications

Type	Description
Series:	PowerTrench®
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	2 P-Channel (Dual)
FET Feature:	Logic Level Gate
Drain to Source Voltage (Vdss):	12V
Current - Continuous Drain (Id) @ 25°C:	700mA
Rds On (Max) @ Id, Vgs:	270mOhm @ 700mA, 4.5V
Vgs(th) (Max) @ Id:	1.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	2.4nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds:	146pF @ 6V
Power - Max:	300mW
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	6-TSSOP, SC-88, SOT-363
Supplier Device Package:	SC-88 (SC-70-6)
