DMC2053UVT-7

Part No :: DMC2053UVT-7

Manufacturer: Zetex Semiconductors (Diodes Inc.)

VIGOR # :: 2980388

Description: MOSFET BVDSS: 8V-24V TSOT26 T&R

Catalog: Transistors - FETs, MOSFETs - Arrays

DataSheet: DMC2053UVT-7 PDF

Current price of DMC2053UVT-7 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

DMC2053UVT-7 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Active
FET Type:	N and P-Channel Complementary
FET Feature:	Standard
Drain to Source Voltage (Vdss):	20V
Current - Continuous Drain (Id) @ 25°C:	4.6A (Ta), 3.2A (Ta)
Rds On (Max) @ Id, Vgs:	35mOhm @ 5A, 4.5V, 74mOhm @ 3.5A, 4.5V
Vgs(th) (Max) @ Id:	1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	3.6nC @ 4.5V, 5.9nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds:	369pF @ 10V, 440pF @ 10V
Power - Max:	700mW (Ta)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	SOT-23-6 Thin, TSOT-23-6
Supplier Device Package:	TSOT-26

Please confirm the specifications of the products when ordering.
