IRF7309TRPBF

Part No :: IRF7309TRPBF

Manufacturer: IR (Infineon Technologies)

VIGOR # :: 2980873

Description: MOSFET N/P-CH 30V 4A/3A 8SOIC

Catalog: Transistors - FETs, MOSFETs - Arrays

DataSheet: IRF7309TRPBF PDF

Current price of IRF7309TRPBF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IRF7309TRPBF Specifications

Type	Description
Series:	HEXFET®
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N and P-Channel
FET Feature:	Standard
Drain to Source Voltage (Vdss):	30V
Current - Continuous Drain (Id) @ 25°C:	4A, 3A
Rds On (Max) @ Id, Vgs:	50mOhm @ 2.4A, 10V
Vgs(th) (Max) @ Id:	1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	25nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds:	520pF @ 15V
Power - Max:	1.4W
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SO
