FDC3601N

Part No :: FDC3601N

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 2981000

Description: MOSFET 2N-CH 100V 1A SSOT-6

Catalog: Transistors - FETs, MOSFETs - Arrays

DataSheet: FDC3601N PDF

Current price of FDC3601N is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

FDC3601N Specifications

Type	Description
Series:	PowerTrench®
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	2 N-Channel (Dual)
FET Feature:	Standard
Drain to Source Voltage (Vdss):	100V
Current - Continuous Drain (Id) @ 25°C:	1A
Rds On (Max) @ Id, Vgs:	500mOhm @ 1A, 10V
Vgs(th) (Max) @ Id:	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	5nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds:	153pF @ 50V
Power - Max:	700mW
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	SOT-23-6 Thin, TSOT-23-6
Supplier Device Package:	SuperSOT™-6
