FQN1N60CTA

Part No :: FQN1N60CTA

Manufacturer: Sanyo Semiconductor/ON Semiconductor

Description: MOSFET N-CH 600V 300MA TO92-3

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: FQN1N60CTA PDF

Availability: 17222000 pieces

Current price of FQN1N60CTA is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

FQN1N60CTA Specifications

Type	Description
Series:	QFET®
Package:	Cut Tape (CT)Tape & Box (TB)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	600 V
Current - Continuous Drain (Id) @ 25°C:	300mA (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	11.5Ohm @ 150mA, 10V
Vgs(th) (Max) @ Id:	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	6.2 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	170 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	1W (Ta), 3W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-92-3
Package / Case:	TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
