DMTH4005SPS-13

Part No :: DMTH4005SPS-13

Manufacturer: Zetex Semiconductors (Diodes Inc.)

Description: MOSFET N-CH 40V 20.9A PWRDI5060

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: DMTH4005SPS-13 PDF

Availability: 12500 pieces

Current price of DMTH4005SPS-13 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

DMTH4005SPS-13 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	40 V
Current - Continuous Drain (Id) @ 25°C:	20.9A (Ta), 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	3.7mOhm @ 50A, 10V
Vgs(th) (Max) @ Id:	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	49.1 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	3062 pF @ 20 V
FET Feature:	-
Power Dissipation (Max):	2.6W (Ta), 150W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	PowerDI5060-8
Package / Case:	8-PowerTDFN
