IRF5801TRPBF

Image is for reference,
please contact us to get the real picture

Part No :: IRF5801TRPBF

Manufacturer: IR (Infineon Technologies)

Description: MOSFET N-CH 200V 600MA MICRO6

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IRF5801TRPBF PDF

Availability: 1301 pieces

Unit Price: ~~$0.54000~~

Current price of IRF5801TRPBF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IRF5801TRPBF Specifications

Type	Description
Series:	HEXFET®
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	200 V
Current - Continuous Drain (Id) @ 25°C:	600mA (Ta)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	2.2Ohm @ 360mA, 10V
Vgs(th) (Max) @ Id:	5.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	3.9 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	88 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	2W (Ta)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	Micro6™(TSOP-6)
Package / Case:	SOT-23-6 Thin, TSOT-23-6

Please confirm the specifications of the products when ordering.
