BS170-D74Z

Part No :: BS170-D74Z

Manufacturer: Sanyo Semiconductor/ON Semiconductor

Description: MOSFET N-CH 60V 500MA TO92-3

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: BS170-D74Z PDF

Availability: 596546000 pieces

Current price of BS170-D74Z is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

BS170-D74Z Specifications

Type	Description
Series:	-
Package:	Cut Tape (CT)Tape & Box (TB)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	500mA (Ta)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	5Ohm @ 200mA, 10V
Vgs(th) (Max) @ Id:	3V @ 1mA
Gate Charge (Qg) (Max) @ Vgs:	-
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	40 pF @ 10 V
FET Feature:	-
Power Dissipation (Max):	830mW (Ta)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-92-3
Package / Case:	TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
