CMPDM202PH TR

Part No :: CMPDM202PH TR

Manufacturer: Central Semiconductor

Description: MOSFET P-CH 20V 2.3A SOT-23F

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: CMPDM202PH TR PDF

Availability: 0 pieces

Current price of CMPDM202PH TR is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CMPDM202PH TR Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Obsolete
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	20 V
Current - Continuous Drain (Id) @ 25°C:	2.3A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	2.5V, 5V
Rds On (Max) @ Id, Vgs:	88mOhm @ 1.2A, 5V
Vgs(th) (Max) @ Id:	1.4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	12 nC @ 5 V
Vgs (Max):	12V
Input Capacitance (Ciss) (Max) @ Vds:	800 pF @ 10 V
FET Feature:	-
Power Dissipation (Max):	350mW (Ta)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	SOT-23F
Package / Case:	SOT-23-3 Flat Leads
