AOB260L

Part No :: AOB260L

Manufacturer: Alpha and Omega Semiconductor, Inc.

Description: MOSFET N-CH 60V 20A/140A TO263

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: AOB260L PDF

Availability: 0 pieces

Current price of AOB260L is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AOB260L Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Not For New Designs
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	20A (Ta), 140A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	2.2mOhm @ 20A, 10V
Vgs(th) (Max) @ Id:	3.2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	180 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	14200 pF @ 30 V
FET Feature:	-
Power Dissipation (Max):	1.9W (Ta), 330W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	TO-263 (D²Pak)
Package / Case:	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
