FDA20N50-F109

Part No :: FDA20N50-F109

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 2896125

Description: MOSFET N-CH 500V 22A TO3PN

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: FDA20N50-F109 PDF

Country of origin: -

Date code: -

FDA20N50-F109 Specifications

Type	Description
Series:	UniFET™
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	500 V
Current - Continuous Drain (Id) @ 25°C:	22A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	230mOhm @ 11A, 10V
Vgs(th) (Max) @ Id:	5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	59.5 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	3120 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	280W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-3PN
Package / Case:	TO-3P-3, SC-65-3
