IRFH8202TRPBF

Part No :: IRFH8202TRPBF

Manufacturer: IR (Infineon Technologies)

Description: MOSFET N-CH 25V 47A/100A 8PQFN

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IRFH8202TRPBF PDF

Availability: 2557 pieces

Current price of IRFH8202TRPBF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IRFH8202TRPBF Specifications

Type	Description
Series:	HEXFET®, StrongIRFET™
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	25 V
Current - Continuous Drain (Id) @ 25°C:	47A (Ta), 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	1.05mOhm @ 50A, 10V
Vgs(th) (Max) @ Id:	2.35V @ 150µA
Gate Charge (Qg) (Max) @ Vgs:	110 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	7174 pF @ 13 V
FET Feature:	-
Power Dissipation (Max):	3.6W (Ta), 160W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	8-PQFN (5x6)
Package / Case:	8-PowerTDFN
