IPB100N06S3-04

Part No :: IPB100N06S3-04

Manufacturer: VIGOR

Description: MOSFET N-CH 55V 100A TO263-3

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IPB100N06S3-04 PDF

Availability: 1000 pieces

Unit Price: ~~$0.84000~~

Current price of IPB100N06S3-04 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IPB100N06S3-04 Specifications

Type	Description
Series:	OptiMOS™
Package:	Bulk
Part Status:	Obsolete
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	55 V
Current - Continuous Drain (Id) @ 25°C:	100A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	4.1mOhm @ 80A, 10V
Vgs(th) (Max) @ Id:	4V @ 150µA
Gate Charge (Qg) (Max) @ Vgs:	314 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	14.23 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	214W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	PG-TO263-3-2
Package / Case:	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB

Please confirm the specifications of the products when ordering.
