IXFB100N50Q3

Part No :: IXFB100N50Q3

Manufacturer: Wickmann / Littelfuse

Description: MOSFET N-CH 500V 100A PLUS264

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IXFB100N50Q3 PDF

Availability: 0 pieces

Current price of IXFB100N50Q3 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IXFB100N50Q3 Specifications

Type	Description
Series:	HiPerFET™
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	500 V
Current - Continuous Drain (Id) @ 25°C:	100A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	49mOhm @ 50A, 10V
Vgs(th) (Max) @ Id:	6.5V @ 8mA
Gate Charge (Qg) (Max) @ Vgs:	255 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	13800 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	1560W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	PLUS264™
Package / Case:	TO-264-3, TO-264AA
