IXTN90P20P

Part No :: IXTN90P20P

Manufacturer: Wickmann / Littelfuse

Description: MOSFET P-CH 200V 90A SOT227B

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IXTN90P20P PDF

Availability: 50 pieces

Current price of IXTN90P20P is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IXTN90P20P Specifications

Type	Description
Series:	PolarP™
Package:	Tube
Part Status:	Active
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	200 V
Current - Continuous Drain (Id) @ 25°C:	90A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	44mOhm @ 500mA, 10V
Vgs(th) (Max) @ Id:	4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs:	205 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	12000 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	890W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Chassis Mount
Supplier Device Package:	SOT-227B
Package / Case:	SOT-227-4, miniBLOC

Please confirm the specifications of the products when ordering.
