APT56F60B2

Part No :: APT56F60B2

Manufacturer: Roving Networks / Microchip Technology

Description: MOSFET N-CH 600V 60A T-MAX

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: APT56F60B2 PDF

Availability: 0 pieces

Current price of APT56F60B2 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

APT56F60B2 Specifications

Type	Description
Series:	POWER MOS 8™
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	600 V
Current - Continuous Drain (Id) @ 25°C:	60A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	110mOhm @ 28A, 10V
Vgs(th) (Max) @ Id:	5V @ 2.5mA
Gate Charge (Qg) (Max) @ Vgs:	280 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	11300 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	1040W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	T-MAX™ [B2]
Package / Case:	TO-247-3 Variant

Please confirm the specifications of the products when ordering.
