FDP12N50

Part No :: FDP12N50

Manufacturer: VIGOR

Description: MOSFET N-CH 500V 11.5A TO220-3

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: FDP12N50 PDF

Availability: 1304 pieces

Current price of FDP12N50 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

FDP12N50 Specifications

Type	Description
Series:	UniFET™
Package:	Bulk
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	500 V
Current - Continuous Drain (Id) @ 25°C:	11.5A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	650mOhm @ 6A, 10V
Vgs(th) (Max) @ Id:	5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	30 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	1.315 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	165W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-220-3
Package / Case:	TO-220-3

Please confirm the specifications of the products when ordering.
