BSC034N10LS5ATMA1

Part No :: BSC034N10LS5ATMA1

Manufacturer: IR (Infineon Technologies)

Description: MOSFET N-CH 100V 19A/100A TDSON

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: BSC034N10LS5ATMA1 PDF

Availability: 0 pieces

Unit Price: ~~$3.53000~~

Current price of BSC034N10LS5ATMA1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

BSC034N10LS5ATMA1 Specifications

Type	Description
Series:	OptiMOS™ 5
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	100 V
Current - Continuous Drain (Id) @ 25°C:	19A (Ta), 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	3.4mOhm @ 50A, 10V
Vgs(th) (Max) @ Id:	2.3V @ 115µA
Gate Charge (Qg) (Max) @ Vgs:	46 nC @ 4.5 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	6500 pF @ 50 V
FET Feature:	-
Power Dissipation (Max):	2.5W (Ta), 156W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	PG-TDSON-8-7
Package / Case:	8-PowerTDFN
