FQD12N20LTM-F085

Part No :: FQD12N20LTM-F085

Manufacturer: Sanyo Semiconductor/ON Semiconductor

Description: MOSFET N-CH 200V 9A DPAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: FQD12N20LTM-F085 PDF

Availability: 35000 pieces

Current price of FQD12N20LTM-F085 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

FQD12N20LTM-F085 Specifications

Type	Description
Series:	Automotive, AEC-Q101, QFET®
Package:	Tape & Reel (TR)
Part Status:	Not For New Designs
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	200 V
Current - Continuous Drain (Id) @ 25°C:	9A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	5V, 10V
Rds On (Max) @ Id, Vgs:	280mOhm @ 4.5A, 10V
Vgs(th) (Max) @ Id:	2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	21 nC @ 5 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	1080 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	2.5W (Ta), 55W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	D-Pak
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63

Please confirm the specifications of the products when ordering.
